Description
SOUNDVISION DCS-990C Digital Chairman Discussion Unit
SOUNDVISION DCS-990C ชุดไมค์ประชุมสำหรับประธาน ระบบดิจิตอล มีปุ่ม Priority สามารถกดตัดการสนทนาระหว่างผู้รวมประชุมได้ ก้านไมโครโฟนยาว 48 ซม. สามารถถอดเก็บได้ มีลำโพงในตัว และ จอแสดงผลการทำงานแบบ TFT LCD ระบบชุดประชุมรองรับได้สูงถึง 5,000 ชุด SOUNDVISION DCS-990C Digital Chairman Discussion Unit จากแบรนด์ชั้นนำ

DCS-990 Series Fully Digital
- สามารถบันทึกเสียงประชุมลง USB
- มีโหมดการจัดประชุมถึง 7 รูปแบบ
- รองรับฟังค์ชั้นระบกล้องติดตามอัตโนมัติ SD/HD สูงถึง 4 ตัว
- มีลำโพงคุณภาพสูงในตัว
- มีเทคโนโลยีขจัดเสียงหวีดหอนในตัว
- ไมค์รองรับการใช้งานพร้อมกัน 60 ตัว
- มาตรฐานการผลิต CE , RoSH
- เคลื่อนย้ายพกพาได้สะดวกและง่ายดาย
DCS-990 รองรับห้องประชุม :
- ห้องประชุมขององค์กร
- ห้องประชุมของหน่วยงานราชการ
- ห้องประชุมสภาเทศบาลเมือง
- สถาบันการศึกษา
- ศาลและมูลนิธิและองค์กรอื่นๆ
คุณสมบัติ
- Digital audio for good sound quality.
- Built-in hi-fi loudspeaker and pluggable microphone.
- Removeable gooseneck microphone with light ring indicator on microphone stem, light up red when microphone turn on.
- High sensitivity microphone and good ability for resistance to Mobile interference.
- Chairman priority key ; could shut all the delegate unit.
- Chairman approve key ; approve the speaking request from delegate unit.
- The chairman unit can be placed in any position in loop.
- The chairman unit quantity is unrestricted in the loop.
- The chairman unit is unrestricted by the limiting function.
- Speaking button and indicator lamp that can show and control the state of speech.
- 3.5mm stereo sound output socket; can be used as earphone connection.
- Volume control for adjusting built-in loudspeaker or headphone volume (when headphone connect).
- Volume control for adjusting microphone volume.
- TFT LCD display microphone ID, Volume level, microphone Mode, etc.
- Daisy-Chain connection.
- Connecting cable 2.1m, 8P core line, convenient installation can increase efficiency.
- The power for units is supplied by the master controller.
- Support automatic video-camera tracking function.
- Reduce sound impact and wind shield.
- Metal microphone shell bottom.
สเปค
| Power Supply | DC 9V by Control unit |
| Power Consumption | 80mA |
| Interface Type | 8P-DIN |
| Earphone Output | 3.5mm stereo jack |
| Installation | Desktop |
| Input Impedance | 1 KΩ |
| Connection Mode | Daisy-Chain |
| Crosstalk Attenuation | >60 dB |
| Speaker Power | 2W |
| Microphone Type | Condenser |
| Polar pattern | Ultra Cardioid |
| Frequency response | 40Hz-18kHz |
| Signal-to-Noise Ratio | 68dB(A-Wieght) |
| Sensitivity | -43 dBV/Pa |
| Length of Microphone | 480mm |
| Color | Silver |
| Diamensions | 125x173x71 mm |
| Weight | 0.75Kg |
แผนภาพ
